- High performance data cable
- PVC Jacket
- CM Rated
- TIA/EIA-568.C.2
- ISO/IEC 11801
- RoHS compliant/UL Listed
Features
Specifications
| DC resistance | Max 9.38 Ω / 100m |
| Rated Voltage | 30V |
| Reference Standard | EIA/TIA 568 & ISO/IEC 11801 |
| Conductor Material | Solid Bare Copper |
| AWG | 24AWG |
| Conductor Diameter | 4 x 2 x 1/0.5 ± 0.01mm |
| Insulation | HDPE |
| Material | PE |
| Average Thickness | 0.21 ± 0.01 mm |
| Insulation Diameter | 0.90 ± 0.01mm |
| High Twisted & Ripcord | Yes |
| Jacket | PVC |
| Average Thickness | 0.63mm |
| Outer Diameter | 5.2 ± 0.01mm |
