Features
True RMS provides better accuracy when measuring non-sinusoidal or noisy waveformsCaptures the instantaneous surge (inrush) current when power equipment is turned on1.2" (30mm) clamp jawBuilt-in Non-Contact Voltage Detector with LEDLow Pass Filter (LPF) for filtering frequency and harmonic interference when measuring variable frequency drivesPeak voltage measurement with Min/MaxData Hold freezes the displayRelative Mode for making comparisons to a stored reference value and DC ZeroAuto power off with disableBuilt-in FlashlightIncludes test leads, Type K thermocouple bead probe, 3 AAA batteries, and carrying case1 year warranty
Specifications
| | | |
| True RMS | ✓ | ✓ |
| Display counts | 6000 count | 6000 count |
| AC Current | 600A | 600A |
| ACA Accuracy | ±2.5% | ±2.5% |
| DC Current | — | 600A |
| AC/DC Voltage | 1000V | 1000V |
| Resistance | 40MΩ | 40MΩ |
| Temperature | -4 to 1832°F (-20 to 1000°C) | -4 to 1832°F (-20 to 1000°C) |
| Capacitance | 100mF | 100mF |
| Frequency | 100kHz | 100kHz |
| Duty Cycle | 20.0 to 80.0% | 20.0 to 80.0% |
| Continuity | <50Ω | <50Ω |
| Lo Pass Filter (LPF) | Yes | Yes |
| NCV Detector | >90V | >90V |
| Inrush Current | 100ms | 100ms |
| Safety Category | CAT III-600V | CAT III-600V |
| Dimensions | 8.8 x 3 x 1.6" (223.8 x 76.5 x 39.4mm) | 8.8 x 3 x 1.6" (223.8 x 76.5 x 39.4mm) |
| Weight | 10oz (282.8g | 10.3oz (290.6g) |
