- Detect faulty wiring in 3-wire receptacles
- Lights display 6 wiring faults:
Open Ground, Open Neutral, Hot/Ground Reverse, Open Hot, Hot/Neutral Reverse, Hot on Neutral with Hot Open - Test GFCI for proper operation
- Built-in Non-Contact Voltage Detector
(80-300V, CAT III-300V) - Includes Transmitter, Receiver and 9V Battery
Features
Applications
One person operation tool for residential and commercial electricians, home inspectors, kitchen and bath installers, apartment/condo property managers, DIY’ers and handymen. The tool features an exclusive comparison mode that identifies the correct breaker, even when signal strengths are very close. The receiver also functions as a Non-Contact Voltage Detector and the transmitter also enables users to detect faulty wiring in 3-wire receptacles and tests GFCI for proper operation.
Specifications
| CBF200 | |
| Receiver | |
| Power | 9V Battery |
| Auto Power Off | After 10 minutes |
| NCV Detector Range | 24 to 600VAC |
| Safety Category | CAT III-300V |
| Transmitter | |
| Voltage | 120VAC |
| Frequency | 47-63Hz |
| GFCI Leakage Current | 7mA @ 120VAC |
| Safety Category | Transmitter: CAT II-300V; NCV: CAT III-300V |
| Dimensions | Transmitter 4.7 x 2.5 x 1.3” (118.5 x 63 x 32mm) Receiver 5.1 x 2.4 x 1.5” (130 x 62 x 36.9mm) |
| Weight | 9.8oz (260g) |
