Professional Analog Insulation Resistance Tester - 1000V Megohmmeter for Electricians | Perfect for Electrical Safety Testing & Maintenance
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:25 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:83942357
Product Description
Feature: 1. Test the insulation resistance with 50V-1000V voltage. 2. Automatic calculation of PI (polarization index) and DAR (dielectric absorption ratio). 3. With backlight display and auto power off. 4. Check the insulation of high voltage electrical equipment such as motor, transformer, cable, etc. 5. Can also be used to AC/DC voltage measurement and continuity test. Spec:Technical ParameterOutput VoltageMeasuring Range Insulation Test 50V (0 %~+20%) 0.01MΩ~50MΩ ±(3%+5) 100V (0%~+20%) 0.01MΩ~100MΩ ±(3%+5) 250V (0%~+20%) 0.01MΩ~250ΩM ±(3%+5) 500V (0%~+20%) 0.01MΩ~500MΩ ±(3%+5) 1.00GΩ~5.00GΩ±(5%+0.1GΩ) 1000V (0%~+20%) 5.00GΩ~10.00GΩ±(10%+0.2GΩ) Short Circuit Current 1.8mA Multimeter Functions DC Voltage Test 0.1~1000V±0.5% AC Voltage Test 0.1~50V±1% Continuity Test 0.01Ω~200Ω±0.5%Characteristics Auto Calculate PI and DAR Data Storage / Loading Data Comparision Auto Discharge for Capacitive Load Timer Function for Insulation Test
Product Features
Test the insulation resistance with 50V-1000V voltage.
With backlight display and auto power off.
Automatic calculation of PI (polarization index) and (dielectric absorption ratio).
Check the insulation of high voltage electrical equipment such as motor, transformer, cable, etc.
Can also be used to AC/DC voltage measurement and continuity test.
